You spoke, we listened. WKmini is a small form factor WKUSB streamlined for use with a contest logging application. It's ideal for Field Day, DXpeditions, mountain topping, or home station use. Speed and message selection are controlled by the host application so a speed pot and message pushbuttons are not needed. Standalone operation is not supported so an internal battery is not required. This allowed us to put WKmini into a very small package. Like WKUSB, it has a custom metal enclosure with RFI and ESD protection. A solid state relay insures a 5 KV isolation barrier between radio and PC, virtually eliminating ground loops and conducted RFI problems. WKmini is based on K1EL's WK3 IC, the best way to connect your PC to an amateur radio transceiver and send Morse both under computer control and by iambic paddle. Morse keying that is generated by a PC based application is prone to timing problems that are a result of the multitasking nature of Windows and other operating systems. All it takes is a long disk search or slow peripheral access to upset the intricate timing of Morse letters. This shows up even more at higher speeds such as you would find in a CW contest. WinKeyer replaces PC generated Morse and produces perfectly timed elements at speeds up to 99 WPM. It is hard to find a contest or logging app that does not support WinKeyer. K1EL created the WinKeyer interface back in 2001 and did a great deal of work convincing software developers to incorporate it into their applications.

WKmini Features
2.25" by 1.7" by .625"
Click for more pictures

Want to learn more about WinKeyer ?
Read this White Paper by K1EL.

WKmini Documentation
WKmini Product Brief
WKmini User Guide
WK3demo Test Application
Winkeyer3 IC Webpage
WKscan - WKUSB port locator
How to restore factory defaults
How to Remap a USB Port
FTDI USB Controller Drivers
WK3.1 Firmware Upgrade Information
WK Apps For Mac OSX
How to Setup N1MM+ for WKmini
Applications that support WinKeyer


Keyer Kits



PIC Tools




WKmini & cables

Contact Us
Frequently Asked Questions
Privacy Policy
About Us

Customer Service

Terms and Conditions
Return & Repair Policy
Ordering Info
Shipping Methods

Copyright 2000-2020 - K1EL Systems LLC
Twitter: @k1elsystems
News: K1EL Systems Blog
Help: K1EL on Groups.io

WKmini - Compact WKUSB Keyer - Rev A
Rev A is not available, Click here for WKmini Rev B

Click for WKmini Cable Information
